2021 DYNAMAX CORP ISATA 5 SERIES 30FW

Mesa, AZ • Dealer • Showroom

37

1

Rv TypeClass C

Length34 ft

Fuel TypeDiesel

Mileage8421 mi

RV DetailsStock #: 585411

ConditionUsed

GVWR19500 lbs

Sleeps6

FloorplanISATA 5 SERIES

A/C Units2

Slide Outs2

Description

ONLY 8,500 MILES!!!

Year: 2021
Manufacturer: Dynamax Corporation
Model: Isata 5 Series 30FW
RV Type: Super C Diesel Motorhome
Chassis: Ram 5500 SLT
Engine: Cummins 6.7L I6 Turbo Diesel
Horsepower: 360 HP
Torque: 800 lb.-ft.
Transmission: AISIN HD 6-Speed Automatic
Drivetrain: Rear-Wheel Drive; 4x4 available as an option
GVWR: 19,500 lbs.
Fuel Capacity: 52 gallons
DEF Capacity: 9 gallons
Rear Axle Ratio: 4.88
Tires: 225/70R19.5G
Wheels: 19.5" aluminum; dual rear wheels
Overall Length: Approx. 33' 3"
Exterior Width: 8'
Interior Ceiling Height: Approx. 6' 10"
Slide-Outs: 2
Sleeping Capacity: Up to 6
Fresh Water Capacity: 78 gallons
Gray Water Capacity: 45 gallons
Black Water Capacity: 45 gallons
LP Capacity: 20.3-gallon tank (WC)
Trailer Hitch Rating: 10,000 lbs.
Tow Connection: 7-way round connector with Ram OEM trailer brake controller
Generator: Onan 8kW Diesel Generator with automatic transfer switch and auto-start
Electrical Service: 50-amp
Inverter: 2,800-watt pure sine wave inverter/charger
House Batteries: Dual Group 27 AGM deep-cycle maintenance-free batteries
Air Conditioning: Dual ducted low-profile 15,000-BTU A/C units with heat pumps
Furnace: 42,000-BTU LP furnace
Water Heater: Truma AquaGo Comfort 60,000-BTU on-demand LP water heater
Holding Tanks: Enclosed and furnace heated
Leveling: Automatic 4-point hydraulic leveling system with Bluetooth
Awning: Dual-pitch armless power patio awning with LED lighting and motion-activated retraction
Exterior: Premium full-body paint with Diamond Shield front-end protection
Construction: 2" aluminum-framed laminated sidewalls, gel-coat fiberglass exterior and one-piece crowned fiberglass roof
