2026 GRAND DESIGN IMAGINE XLS 22MLE
16
Rv TypeTravel Trailer
Length26 ft
Fuel Type-
Mileage-
RV DetailsStock #: 51590
ConditionNew
GVWR
Sleeps4
FloorplanIMAGINE XLS
Slide Outs1
Water Cap.
Description
2026 GRAND DESIGN IMAGINE XLS 22MLE,
Specifications and Features:
Specifications and Features:
- Exterior Length: 26' 1"
- Exterior Width: 8'
- Exterior Height: 10' 10"
- Interior Height: 6' 6"
- Dry Weight (UVW): 5,423 lbs
- Gross Vehicle Weight Rating (GVWR): 6,995 lbs
- Hitch Weight: 608 lbs
- Fresh Water Capacity: 37 gallons
- Gray Water Capacity: 45 gallons
- Black Water Capacity: 37 gallons
- Propane Capacity: 40 lbs (two 20 lb tanks)
- Sleeping Capacity: 4
- Slideouts: 1
- Air Conditioning: 15,000 BTU
- Furnace: 25,000 BTU
- Water Heater: Tankless
- Refrigerator: 12V, 10 cu. ft.
- Cooktop: 3-burner range with oven
- Microwave: Yes
- Shower: 27" x 36" residential walk-in shower
- Bed: 60" x 80" queen bed
- Awning: 18' electric with LED light
- Tire Size: ST205/75R14LRD
- Axles: 2
- Construction: Aluminum cage with fiberglass sidewalls
- Insulation: Roof R-40, Wall R-7, Floor R-30, Slide Room R-7
- Exterior Features: Aluminum entry steps, power tongue jack, spare tire & carrier, exterior speakers, external shower, ladder, backup camera prep
- Interior Features: Deep-seated stainless steel sink, residential pull-down sprayer faucet, residential cabinetry, high-definition LED TV, surround sound system, TV and cable prep, exterior cable hookup
- Safety Features: CO detector, LP detector, smoke detector
- Electrical: 30 AMP service, 200W roof-mounted solar panel, 30 AMP charge controller, 12V 10 cu. ft. refrigerator
- HVAC: High-capacity furnace, designated heat to subfloor, residential (ductless) heating system throughout, ducted main A/C
- Plumbing: High-capacity water pump, oversized tank capacities, shut-off valves
- Bedroom: Master suite with queen bed, built-in wardrobe cubby storage with USB-C charging station and 110V outlet
- Bathroom: Residential walk-in shower, skylight over shower, power vent fan, undermount sink, soft-close porcelain toilet seat lid, medicine cabinet with mirror
