2026 GRAND DESIGN IMAGINE XLS 22RBE
29
Rv TypeTravel Trailer
Length26 ft
Fuel Type-
Mileage-
RV Details
ConditionNew
GVWR
Sleeps4
FloorplanIMAGINE XLS
Slide Outs1
Water Cap.
Description
2026 GRAND DESIGN IMAGINE XLS 22RBE,
Specifications and Features:
Specifications and Features:
- Exterior Length: 25' 11"
- Exterior Width: 8'
- Exterior Height: 10' 10"
- Interior Height: 6' 6"
- Dry Weight (UVW): 5,379 lbs
- Gross Vehicle Weight Rating (GVWR): 6,995 lbs
- Hitch Weight: 618 lbs
- Fresh Water Capacity: 37 gallons
- Gray Water Capacity: 82 gallons
- Black Water Capacity: 37 gallons
- Sleeping Capacity: 4
- Slideouts: 1
- Furnace: 25,000 BTU
- Air Conditioner: 15,000 BTU
- Refrigerator: 12V, 10 cu. ft.
- Cooktop Burners: 3
- Water Heater: On-Demand Tankless
- Awning: 18' Electric with LED Light
- Axles: 2
- Tire Size: ST205/75R14LRD
- LP Tank Capacity: 20 lbs (x2)
- Electrical Service: 30 amp
- Shower Type: Walk-In Shower
- Available Beds: Queen
- TV Info: LR LED HDTV
- Construction Type: Aluminum Cage
- Floor R-Value: R-30
- Wall R-Value: R-7
- Roof R-Value: R-40
- Slide Room R-Value: R-7
- Standard Bed: 60 x 80 Queen Bed
- Shower Dimensions: 27 x 36
- Solar Package: 200W Roof Mounted Solar Panel, 40 Amp Charge Controller, 12V 10 Cu. Ft. Refrigerator, Roof Mounted Quick Connect Plugs
- Peace of Mind Package: Aluminum Entry Steps, Deep Seated Stainless Steel Sink, Residential Pull-Down Sprayer Faucet, Residential Cabinetry, Double Insulated Roof and Front Wall, Heated and Enclosed Dump Valves
- Four Season Protection Package: Heated and Enclosed Underbelly with Suspended Tanks, Designated Heat Duct to Subfloor, Residential (Ductless) Heating System Throughout, Ducted Main A/C
- Ultimate Power Package: Electric Awning with LED Light, Power Tongue Jack, LED Interior Lighting, Motion Sensor Pass Thru Lighting (LED), Motion Sensor Entry Lighting (LED), Bluetooth Stereo, High Definition LED Television, Detachable Power Cord with LED Light, 30 AMP Service, 15k Ducted Main A/C, 25k BTU Furnace, Black Tank Flush, Battery Kill Switch (Pass Thru), Aluminum Wheels, Spare Tire and Carrier, Nitrogen Filled Radial Tires, Magnetic Storage and Entry Door Latches
- Interior Features: Residential Walk-In Shower, Skylight Over Shower, Power Vent Fan,
